-60℃~ -20℃ Industrial Cooling Circulator/ Circulating Chiller

The basic principle of a circulating chiller is that the temperature of a system or object is governed by the heat flow into it and the heat flow out of it.
Circulating chillers are used to do low temperature experiment such as chemical, biological and physical experiment in low temperature. It is normally used for cooling:

Evaporators (Rotary evaporator, Wiped Film Evaporator)
Distillation Equipment ( Fractional Distillation, Wiped Film Distillation and Other Vacuum Distillation)
Reactors (Glass and Stainless Reactors)
Solvent Extraction Equipment ( Cooling Ethanol)

Refrigeration Compressors And Other Key Parts Are Imported With High Quality And High Reliability And Efficiency
Digital Setting And Display Of Temperature For Easy Operation
Large Cooling Capacity And Fast Cooling Down
Low Noise And StableConstant Running With Low Maintenance Rates


Availability:



Inquiry Email

Model:
VCC-6062
Brand:
Valuen

Product Overview

Product Parameter

About US

Refrigeration Compressors and Other Key Parts Are Imported with High Quality and High Reliability and Efficiency

Digital Setting and Display of Temperature for Easy Operation

Large Cooling Capacity and Fast Cooling Down

Low Noise and Stable Constant Running with Low Maintenance Rates

-60~-20℃ chiller

heater_11

heater_22

heater_33

Model		VCC-6018	VCC-6030	VCC-6062	VCC-6090	VCC-60A1	VCC-60A2
Temperature Range		-60℃~-20℃
Cooling Capacity	-20℃	0.85KW	1.45KW	2.5KW	3.4KW	4.8KW	7.2KW
	-40℃	0.7KW	1.2KW	2.1KW	2.8KW	4KW	6KW
	-55℃	0.4KW	0.6KW	1.2KW	1.6KW	2KW	3KW
Circulation Pump Flow Rate		Max20L/min		Max35L/min		Max70L/min
Circulation Pump Pressure		0.7BAR		1BAR
Liquid Storage Volume		15L	20L	25L	30L	35L	45L
Interface Size		DN15	DN20	DN20	DN20	DN20	DN20
Safety Protection		High pressure switch, overload relay, thermal protection device and other safety guarantee functions
Power Supply MAX 50HZ		AC220V50HZ 2.5KW	AC380V50HZ 3.8KW	AC380V50HZ 4.5KW	AC380V50HZ 6.5KW	AC380V50HZ 8KW	AC380V50HZ 10.5KW
Optional Power Supply		220V 60HZ 3-phase,440V～480V 60HZ 3-phase
